Road bike size chart

Road and gravel frames are sized in centimetres or letters. Find your height, then check the frame with your inseam: inseam × 0.665 gives the frame size in cm.

Height	cm	Generic	Specialized Tarmacframe size	Canyon Endurace	bike-discount.deframe size
4′10″–5′1″	148–155	XXS, 44–47 cm	44	3XS	–
5′1″–5′4″	155–163	XS, 48–50 cm	49	3XS or 2XS	50
5′4″–5′7″	163–170	S, 51–53 cm	52	XS	50 or 53
5′7″–5′10″	170–178	M, 54–55 cm	54 or 56	S	56
5′10″–6′1″	178–185	L, 56–58 cm	56 or 58	M	58 or 60
6′1″–6′4″	185–193	XL, 58–60 cm	58 or 61	L or XL	60 or 62
6′4″ +	193 +	XXL, 61 cm +	61	XL or 2XL	–

Sources: Specialized size guide, Canyon Endurace geometry, bike-discount.de frame size calculator, checked 30 Oct 2026. Gravel bikes such as the Specialized Diverge follow the same heights.

Print this chart

The road bike size chart on one page, A4 or US Letter. Free to print for shops, schools and clubs.

Download the PDF

What frame size for my inseam?

Multiply your inseam in cm by 0.665 to get a frame size in cm.

Inseam 84 cm × 0.66555.9 cm: an L (56–58 cm)
Height 178 cm (5′10″)L band, 178–185 cm
ResultHeight and inseam agree: L. Specialized 56, Canyon M.

A woman in a red jersey riding a blue road bike, seen from the side, with her leg almost straight at the bottom of the pedal stroke

How high should the saddle be?

Start at your inseam × 0.883, measured from the centre of the cranks to the top of the saddle. An 84 cm (33″) inseam gives 74.2 cm (29.2″). Then adjust in small steps.

Source: calculate.co.nz, after Greg LeMond’s formula.

How much standover clearance do I need?

Straddle the bike with both feet flat. REI suggests about 2.5 cm (1″) of clearance over a level top tube and 5 cm (2″) or more over a sloping one. Brands list standover height in their geometry tables; subtract it from your inseam.

Source: REI bike fit.

Your road bike size

Height

ftin

Inseam (optional, makes it more exact) Inseam = inside leg. From the floor to the crotch, in bare feet. It’s not the inseam on a jeans label. Stand against a wall, pull a book up between the legs like a saddle, mark its top edge and measure down to the floor. Step by step →

in cm

Your inside leg: floor to crotch, in bare feet. How to measure it.

Start withL56–58 cm frame

Your inseam points to L: your legs are long for your height, and the frame has to fit your legs.

M also fits. Your height alone says M. It’s shorter and nimbler, with a lower top tube.

Your size is marked in the chart. The bike size calculator adds saddle height and each brand’s name for your size.

Shop your size

Links open the shop’s own pages. No shop pays for a result.

Road bike size questions

What size road bike for 5′9″?

Usually M, a 54–55 cm frame. With a long inseam (over about 83.5 cm or 33″) the formula points to L. Specialized calls it a 54 or 56, Canyon an S.

Do I size a gravel bike the same way?

Yes. Gravel frames use the same height bands. Some riders size down for a shorter reach and more control off-road.

Where does the saddle go?

Start at inseam × 0.883, measured from the centre of the cranks to the top of the saddle, then adjust in small steps.
